GD32C2x1系列
-
概述
-
产品组合
-
产品选择器
-
文档
概述
GD32C2x1系列MCU在维持优异价值竞争力的同时 ，显著提升运算机能与表设规格 ，实现超高性价比升级。该系列选取Arm先进的Cortex?-M23内核架构 ，机能比 Cortex? M0+ 提高10% ，主频可达48MHz ，具备单周期乘法和整数除法运算等高效处置能力 ，大幅提升软件执行效能。存储配置方面 ，搭载32KB~64KB高靠得住嵌入式Flash和12KB低功耗SRAM ，全存储区域均建设ECC纠错职能。为满足分歧利用场景需要 ，提供TSSOP20/LGA20 ，QFN28 ，LQFP32/QFN32以及LQFP48 /QFN48等多种封装选择。
GD32C2x1系列MCU提供多达4个通用16位按时器、1个16位高级按时器。建设2路高速SPI接口（支持四线QSPI模式 ，速度达24Mbps）、2路I2C接口（支持Fast Mode+ ，速度1Mbit/s）和3路UART（速度6Mbps） ，集成3路DMA节造器 ，1路I2S ，确保高效通讯能力。极度适合利用在幼家电、白电、BMS电池治理系统、幼型显示设备、便携式消费电子产品、工业辅助节造系统以及车载后装设备等场景。
索求9888拉斯维加斯产品组合
-
选取Cortex?-M23内核 ，主频达48MHz 存储容量支持32KB~64KB Flash和12KB SRAM
产品选择器
14条了局
|
Part No.
|
Core
|
Series
|
Package
TSSOP20
QFN48
QFN32
QFN28
LQFP48
LQFP32
LGA20
|
Max Speed (MHz)
|
Flash (Bytes)
32K
64K
|
SRAM (Bytes)
|
I/O
18
26
30
45
|
GPTM (32bit)
|
GPTM (16bit)
|
Advanced TM (16bit)
|
HRTM
|
Basic TM (64bit)
|
CPTM (16bit)
|
Basic TM (32bit)
|
Basic TM (16bit)
|
LPTM (32bit)
|
LPTM (16bit)
|
SysTick (64bit)
|
SysTick (24bit)
|
WDG
|
RTC
|
USART+UART
2
3
|
LPUART
|
I2C
|
QSPI
|
SPI
|
I2S
|
CAN 2.0B
|
USB 2.0
|
Ethernet
|
SDIO
|
EtherCAT Slave Controller
|
MFCOM
|
LIN
|
LCD-TFT
|
MIPI-DSI
|
Segment LCD
|
Camera
|
IPA
|
SAI
|
TMU
|
EXMC
|
CEC
|
14bit ADC Units (CHs)
|
12bit ADC Units (CHs)
1(9)
1(13)
1(12)
1(11)
|
12bit DAC Units
|
Comp
|
IEEE 802.11
|
Bluetooth
|
Dflash(Bytes)
|
SENT
|
Functional Safety
|
Security
|
Temperature Range(TA)
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Cortex?-M23 | GD32C231 | LQFP48 | 48 | 32K | 12K | 45 | 0 | 4 | 1 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 4 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(13) | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M23 | GD32C231 | LQFP48 | 48 | 64K | 12K | 45 | 0 | 4 | 1 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 4 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(13) | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M23 | GD32C231 | QFN48 | 48 | 32K | 12K | 45 | 0 | 4 | 1 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 4 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(13) | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M23 | GD32C231 | QFN48 | 48 | 64K | 12K | 45 | 0 | 4 | 1 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 4 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(13) | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M23 | GD32C231 | LQFP32 | 48 | 32K | 12K | 30 | 0 | 4 | 1 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 4 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(12) | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M23 | GD32C231 | LQFP32 | 48 | 64K | 12K | 30 | 0 | 4 | 1 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 4 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(12) | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M23 | GD32C231 | QFN32 | 48 | 32K | 12K | 30 | 0 | 4 | 1 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 4 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(12) | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M23 | GD32C231 | QFN32 | 48 | 64K | 12K | 30 | 0 | 4 | 1 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 4 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(12) | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M23 | GD32C231 | QFN28 | 48 | 32K | 12K | 26 | 0 | 4 | 1 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 2 | 0 | 4 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(11) | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M23 | GD32C231 | QFN28 | 48 | 64K | 12K | 26 | 0 | 4 | 1 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 2 | 0 | 4 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(11) | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M23 | GD32C231 | TSSOP20 | 48 | 32K | 12K | 18 | 0 | 4 | 1 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 2 | 0 | 4 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M23 | GD32C231 | TSSOP20 | 48 | 64K | 12K | 18 | 0 | 4 | 1 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 2 | 0 | 4 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M23 | GD32C231 | LGA20 | 48 | 32K | 12K | 18 | 0 | 4 | 1 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 2 | 0 | 4 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M23 | GD32C231 | LGA20 | 48 | 64K | 12K | 18 | 0 | 4 | 1 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 2 | 0 | 4 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ |
